Steca Solarix PLI 2400-24 Solar Inverter Charger

Steca Solarix PLI 2400-24 – All-in-One Solar Inverter Charger

Made in Europe 🇪🇺

The Steca Solarix PLI 2400-24 is a professional all-in-one solar inverter charger that combines a pure sine wave inverter, an integrated MPPT charge controller, and a transfer switch in a single compact unit. It supplies consumers with 230 V AC power, charges batteries from solar panels or the grid/generator, and switches between power sources in just 10 ms — making it ideal as an uninterruptible power supply (UPS).

Key Features

• All-in-one: pure sine wave inverter + MPPT solar charger + AC transfer switch
• Continuous power: 2400 W / 3000 VA
• System voltage: 24 V DC
• Max. efficiency (sine wave): > 91%
• Max. efficiency (charge controller): > 98%
• UPS function: 10 ms transfer time
• Input voltage: 90 V AC … 280 V AC
• Output voltage: 220 V AC … 240 V AC +/–5%
• Output frequency: 50 / 60 Hz
• Max. charge current from AC: 60 A (programmable)
• Max. charge current from PV: 40 A
• MPPT voltage range: 30 V … 80 V
• Nominal charge power: 1168 W
• Battery voltage range: 20 V … 30 V
• Programmable battery type (liquid)
• Dual overload capability for starting large AC motors
• Compatible with Fernlite monitoring system

Technical Specifications

• Dimensions: 275 x 385 x 114 mm
• Weight: 7.6 kg
• Operating temperature: 0°C … +55°C
• Storage temperature: –15°C … +60°C
• Relative humidity: < 90%, non-condensing
• Maximum altitude: 2000 m a.s.l.
• Degree of protection: IP 21
• Cooling: fan
• Terminal AC: 6 mm² – AWG 8
• Terminal PV: 6 mm² – AWG 8
• Battery connection: 35 mm² … 50 mm² (AWG 2 … AWG 0, M6 ring terminal included)
